mytouchsmart timer instructions

Welcome to the myTouchSmart Timer guide! This digital timer simplifies automation for indoor/outdoor lights and devices․ Compatible with LED, CFL, and incandescent bulbs, it offers programmable schedules, manual overrides, and daylight saving adjustments for seamless control․ Follow these instructions to install, set up, and troubleshoot your timer effectively․

Overview of the myTouchSmart Timer Features

The myTouchSmart Timer offers a range of convenient features for automating lights and devices․ It includes programmable on/off schedules, manual override options, and automatic daylight saving time adjustments․ Compatible with LED, CFL, incandescent, and halogen bulbs, this timer supports up to 15A general/resistive loads․ Features like battery backup and a simple setup process ensure uninterrupted operation․ With options for daily, weekly, or custom schedules, it provides flexibility for any routine․ The timer also includes a blue LED indicator and remote control compatibility for enhanced convenience․

Installation and Setup

Plug the timer into an outlet and charge for 1 hour․ Press the reset button using a toothpick or pencil to begin setup․

Mounting the Timer

Mount the timer on a wall near a GFCI receptacle using a screw or nail․ Ensure it is installed vertically and as high as possible above ground level․ For outdoor use, face the receptacle downward to avoid water exposure․ Avoid areas where water may splash or drip onto the timer․ Secure the timer firmly to prevent movement or damage․ If unsure about installation, consult a licensed electrician․ Proper mounting ensures safe and reliable operation of the timer for controlling your lights or devices․

Connecting Devices to the Timer

Plug your devices into the timer’s outlets, ensuring compatibility with LED, CFL, incandescent, or halogen bulbs․ For models like the 35150 or 36253, connect up to two devices․ Set your desired schedule using the programmable buttons․ Press “My On Time” and adjust using the up/down arrows․ Once set, the timer will automatically control your devices․ Ensure the total connected load does not exceed the timer’s capacity (e․g․, 1200W for tungsten or 1200VA for ballasts)․ This setup allows seamless automation for lights, fans, or other compatible appliances․

Power Requirements and Safety Precautions

The myTouchSmart Timer operates on 120VAC, 60Hz power and supports up to 15A general/resistive loads (1200W tungsten, 1200VA ballast)․ Ensure the timer is mounted near a GFCI receptacle, avoiding water exposure․ Do not install in areas where the timer could be submerged or splashed․ Always turn off power at the circuit breaker before installation․ For in-wall models, consult a licensed electrician if unsure․ Avoid exceeding the timer’s load capacity to prevent damage or hazards․ Use with compatible devices only, such as dimmable LED, CFL, or halogen bulbs, to ensure safe and reliable operation․

Programming the Timer

The myTouchSmart Timer allows easy scheduling with custom on/off settings and manual override․ Program specific times and adjust for daylight saving automatically for convenient control․

Setting the Current Time and Date

To set the current time and date on your myTouchSmart Timer, start by plugging it into a power outlet and allowing it to charge for 1 hour․ Press the reset button (usually located at the bottom) using a toothpick or pencil to initialize the timer․ Use the up and down arrows to set the desired time and date․ The timer will automatically adjust for Daylight Saving Time unless you disable this feature․ Ensure the time is accurate for proper scheduling of your devices․ This step is essential for all programmable functions to work correctly․

Custom On/Off Settings and Schedules

Program your myTouchSmart Timer with custom on/off settings to automate your devices․ Press the “My On Time” button and use the up/down arrows to set your desired activation time․ Repeat the process for the “My Off Time” to complete the schedule․ You can create multiple schedules for different times of the day or week․ The timer also features a manual override option, allowing temporary control of connected devices․ Ensure the current time and date are set correctly before programming for accurate operation․ This feature is ideal for managing lights, fans, or appliances efficiently and energy-consciously․

Manual Override and Daylight Saving Time Adjustments

Easily override schedules with the manual control feature․ Adjust the timer for Daylight Saving Time by pressing the up or down arrows to shift the time by one hour․

Using Manual Override for Temporary Control

Press the “My On” button to activate devices manually until the next scheduled event․ Similarly, the “My Off” button turns them off temporarily․ The timer resumes its programmed schedule afterward, ensuring seamless control without altering the set plan․ This feature is ideal for occasional adjustments, providing flexibility while maintaining automated routines․ Use these buttons as needed to override the timer’s settings temporarily․

Adjusting for Daylight Saving Time

The myTouchSmart Timer automatically adjusts for Daylight Saving Time (DST), shifting time forward or backward by one hour․ If your area does not observe DST, disable this feature in the settings menu to prevent unwanted time changes․ During DST transitions, manually adjust the timer by pressing the up or down arrows to set the correct time․ Ensure the timer is in “DST ON” or “DST OFF” mode accordingly․ This feature ensures seamless timekeeping and maintains programmed schedules accurately throughout the year․ Adjusting for DST is crucial for consistent automation of your connected devices․

Troubleshooting Common Issues

If the timer stops working or the display malfunctions, check power connectivity and ensure proper installation․ Reset the timer using a toothpick or pencil if issues persist․

Timer Not Working or Display Issues

If your myTouchSmart timer stops working or the display is unresponsive, start by ensuring it is properly plugged in and the outlet has power․ Check for any tripped circuit breakers or blown fuses․ If the display is blank, press the reset button using a toothpick or pencil․ Verify that the time and date are correctly set, as incorrect settings can cause malfunctions․ If the timer has a battery backup, ensure it is charged or replace it if necessary․ If issues persist, perform a factory reset by holding the reset button for 10 seconds․ Contact customer support if problems remain unresolved․

Resetting the Timer to Factory Settings

To reset your myTouchSmart timer to factory settings, ensure it is plugged into a powered outlet․ Locate the small reset button (usually marked with a circle or “R”) on the bottom or side of the timer․ Use a toothpick or pencil to press and hold the reset button for 10-15 seconds until the display clears or flashes․ Release the button and unplug the timer for 30 seconds․ Plug it back in and press the reset button again briefly to reboot․ The timer will revert to default settings, requiring you to reprogram schedules and preferences․ Ensure the battery (if applicable) is charged before proceeding․

Safety Precautions and Maintenance

Ensure safety by following installation guidelines and avoiding water exposure․ Avoid overloading the timer and keep it away from flammable materials․ Regularly clean and inspect for optimal maintenance and longevity․

Ensuring Safe Installation and Operation

For safe installation, mount the timer near a GFCI receptacle using a screw or nail, ensuring it’s vertical and above ground to prevent water exposure․ Avoid immersing the device or placing it where water may splash․ Turn off power at the circuit breaker before installation․ Operate the timer on a 120VAC, 60Hz supply, ensuring it’s not overloaded․ Keep it away from flammable materials and avoid touching electrical components․ Regularly inspect for damage and clean dust to maintain functionality․ Follow all safety guidelines to prevent hazards and ensure reliable operation․

Maintenance Tips for Longevity

Regularly clean the timer’s surface with a dry cloth to prevent dust buildup․ Reset the timer seasonally or during daylight saving changes to ensure accuracy․ Avoid overloading the timer with devices exceeding its wattage capacity․ For models with battery backup, replace batteries every 2-3 years or when the display dims․ Check connections periodically to ensure they are secure․ Store the timer in a dry, cool place when not in use․ By following these tips, you can extend the lifespan of your myTouchSmart Timer and ensure optimal performance․
